SII Semiconductor Corporation Introduces a New 2-to-3-Cell Secondary Battery Protection IC for Rechargeable Li-ion Batteries Utilizing an Ultra-small Package



SII Semiconductor Corporation, a subsidiary of Seiko Instruments Inc., introduces the S-8223A/B/C/D Series 2-to-3 cell secondary battery protection IC for lithium-ion rechargeable batteries. They are characterized by an ultra-small SNT-6A package measuring 1.6 x 1.8 x 0.5 mm and a current consumption of only 0.25 μA.  The current consumption is one fourth of existing products so this makes the S-8223 A/B/C/D Series the lowest in the industry*1. The S-8223A/B/C/D Series is ideal for protecting lithium-ion batteries in laptop computers and other portable devices.

Lithium-ion batteries require protection from overcharge, overdischarge, overcurrent and short circuits. The use of a secondary protection IC like the S-8223A/B/C/D Series is especially critical in cases of overcharge conditions which may result in heating and ignition of the lithium-ion batteries. The S-8223A/B/C/D Series provides the design engineer with another robust layer of safety.

The main feature of the newly introduced S-8223A/B/C/D Series is the ultra-small SNT-6A package measuring 1.6 x 1.8 x 0.5 mm, which leads to a reduction in the size, thickness and weight for portable devices. Secondly, the industry’s lowest operating current consumption of 0.25 μA, helps prolong the battery operating time. Lastly, the S-8223 Series has the industry’s highest class*2 accuracy in overcharge detection voltage at ±20 mV. This provides enhanced safety monitoring of lithium-ion rechargeable batteries. The S-8223B/D Series has a gate connection terminal of the charge control FET equipped with an output voltage control circuit, meaning the series is also compatible with a FET at a gate-source withstanding voltage of 12 volts.

*1, *2: Source: SII Semiconductor Corporation, among the lithium-ion battery protection ICs as of July 2017



Data Sheet
http://datasheet.sii-ic.com/en/battery_protection/S8223A_B_C_D_E.pdf



About SII Semiconductor Corporation

SII Semiconductor Corporation, a semiconductor manufacturer in Seiko Instruments Group, offers analog semiconductor products such as Power Management ICs, EEPROMs, Sensors, Timer ICs, Amplifiers and ASSPs; featuring small size, low current consumption and high accuracy.

http://www.sii-ic.com/en/
