IC matching information

SII conducts circuit matching investigation of our quartz oscillator. The results of the survey will be disclosed below.

Company Name              IC Type/Matching Data
ABLIC Inc.

S-35190A/S-35192A/S-35390A/S-35391A/S-35392A
S-35710/S-35720/S-35730/S-35740
GigaDevice Semiconductor Inc. GD32E230
GD32F303
Microchip Technology Inc.

ATxmega series
ATtiny series
PIC18 series
Nordic Semiconductor nRF514 series
nRF52 series
nRF53 series
Renesas Electronics RA8M1 group
RA21L group
RX671 group
RX660 group
RX261/RX260 group
RX140 group
DA1458x series
R7F0E01x (RE0 series)


ROHM Co., Ltd.









ML62Q1000 series
ML62Q2000 series
ML63Q2500 group
STMicroelectronics STM32 series
Texas Instruments Incorporated ㏄26xx series

※Please contact us for other products.

Please contact us for the result of detailed usage.

The crystal resonator is a passive component.

There is a possibility that the oscillation state may be changed depends on the IC or board condition.

We recommend to do circuit matching for appropriate usage.
