Quartz Crystal

32 kHz tuning-fork type quartz crystal resonator

32 kHz Tuning-fork type Quartz crystal rsonator

New product TOPIX

We have released a new product, the "SC-16P," which achieves low ESR in a 1610 size. The SC-16P features a typical ESR of 37kΩ and exhibits low ESR characteristics over a wide operating temperature range.
(Maximum temperature range: -55°C to +125°C)
By achieving both miniaturization and low ESR, it contributes to power saving in various electronic devices.

Specifications are available here >>

PRESS RELEASE

SII Begins Mass Production of the World’s Smallest 1008 size (1.0 × 0.8 × 0.32mm) Tuning-Fork Crystal Resonator “SC-10S”
Achieving Both a 33% Reduction in Mounting Area and Low ESR.

Read More

32kHz Tuning-Fork Crystal Resonator Product Information

Technical specification for crystal units optimized for

Oscillator（TCXO）

Crystal Oscillator (SH-32R)

Technical overview of crystal units optimized for SPXO (Simple Packaged Crystal Oscillator) applications. These units are designed for easy integration with oscillation ICs to provide a stable clock source. They feature a balanced design that ensures reliable startup and consistent frequency output for general-purpose electronic systems

Oscillator（SPXO）

Crystal Oscillator (SN-20S)
