IC matching information

SII conducts circuit matching investigation of our quartz oscillator. The results of the survey will be disclosed below.

A report on circuit matching investigations between SII quartz oscillators and ICs from GigaDevice Semiconductor Inc. The results provide optimized circuit parameters and compatibility data to ensure reliable oscillation and stability when using GigaDevice semiconductor components.

GigaDevice Semiconductor Inc.

IC Type/Matching Data

GD32E230

GD32F303

A report on circuit matching investigations between SII quartz oscillators and ICs from Microchip Technology. The results provide optimized circuit parameters and compatibility data to ensure stable and reliable oscillation performance when using Microchip semiconductor components

Microchip Technology Inc.

IC Type/Matching Data

ATxmega series

ATtiny series

PIC18 series

Nordic Semiconductor

IC Type/Matching Data

nRF514 series

nRF52 series

nRF53 series



A report on circuit matching investigations between SII quartz oscillators and ICs from ROHM Semiconductor. The results provide optimized circuit parameters and compatibility data to ensure stable and reliable oscillation performance when integrated with ROHM semiconductor products

ROHM Co., Ltd.

IC Type/Matching Data

ML62Q1000 series

ML62Q2000 series

ML63Q2500 group

STMicroelectronics

IC Type/Matching Data

STM32 series



Texas Instruments Incorporated

IC Type/Matching Data

㏄26xx series

※Please contact us for other products.

Please contact us for the result of detailed usage.

The crystal resonator is a passive component.

There is a possibility that the oscillation state may be changed depends on the IC or board condition.

We recommend to do circuit matching for appropriate usage.
