| Printing |
Method |
Thermal line dot printing |
| Number of dots/line |
432 |
| Resolution (dots/mm) |
8 |
| Paper width (mm) |
Restick liner-free label, Receipt paper : 40 , 58
Label (Liner width) : 31 to 58 |
| Printing width (mm) |
Restick liner-free label, Receipt paper : 36 , 54 |
| Speed (mm/sec) max |
200 |
| Outside diameter of paper roll (mm) max |
ф 102 |
| Character matrix (H×W mm) |
24 x 12, 24 x 24, 16 x 8, 16 x 16 |
| Character dimensions (H×W mm) |
3.0 × 1.5, 3.0 × 3.0, 2.0 × 1.0, 2.0 × 2.0 |
| Type of Paper |
Media Type |
Restick liner-free label, Receipt paper, Label with liner
Roll paper (Drop in) |
| Top margin (mm) min |
4 |
| Paper sensor |
Out of paper sensor, Timing mark sensor, Label taken sensor |
| Character type |
Code page (18Pages), International character, Optional font,
Downloaded character, JIS 1&2 Level Kanji,
Special character, User-defined character |
| Bar code |
UPC-A/E, JAN(EAN)8/13, ITF, CODABAR, Code39, Code93, Code128,
QR code, PDF417, Maxi code, Data matrix, GS1 Databar |
| Power supply |
Specified AC adapter, External power (DC24±10%) |
| Communication interface |
USB, Ethernet+USB, Wireless LAN |
Bluetooth® + USB |
| Command |
ESC/POS™(Standard mode) conformity |
| Cutting method |
Slide type |
| Cutting type |
Full cut, Partial cut (Leave center point) |
| Operating Temperature (°C) |
5 to 45 |
| Service life |
Paper cutting (cut) |
Restick liner-free label, Receipt paper: 1,000,000*1
Liner label: 300,000*1 |
| Dimensions (W×D×H mm) |
90 x 200 x 141*2 |
| Mass (g) |
Approx. 1100 |
| Standard |
FCC, CE, UKCA, VCCI |
| Software*3 |
Windows®: Printer Driver / OPOS / POS for .NET / Utility / Layout Editor / Smart Label Creator
Android™: Printer Class Library / URL Print Agent / Layout Editor / Smart Label Creator / MAUI SDK / Utility
iOS: Printer Class Library / URL Print Agent / Layout Editor / Smart Label Creator / MAUI SDK / Utility |
